VCSIDE icon

VCSIDE

Atari 2600 game program development system

Available for macOS · Windows · Linux

What it is

A small IDE that knows the 2600

VCSIDE is a native program for writing Atari 2600 games in assembly, batari Basic or C for ELF and ACE cartridges. It counts cycles as you type, draws sprites the way the TIA will, tells you how much room is left in every bank and starts Stella or Gopher2600 with your breakpoints already set.

The goal is a tool that is light on resources, gets the job done, and is fully integrated with everything you need to make, test and debug a 2600 game: the assembler or compiler, the emulators and their debuggers, the graphics and the documentation, all in one place.

It is one executable built with C++ and Dear ImGui, the same on macOS, Windows and Linux. It is not an editor plug-in: it is made only for the 2600, and everything in it is about the console.

VCSIDE with an assembly program, its cycle column and the project panel
An assembly project: the cycle column next to the code, help on hover and the space left in the status bar.

New in 0.2.0

Music, an assistant and a game to start from

What's in the box

Every part, explained in the manual

Cycle-counting editor

A cycle column on every instruction, totals for a selection, help on hover, completion and jumps to a definition.

The code editor →

Build and debug

DASM, batari Basic or make with F7. Errors on their line, F5 to run, F6 to debug with breakpoints in Stella or Gopher2600.

Build, run and debug →

Space report

Bytes used and free per bank, RAM left for the stack, cartridge RAM, and the flash and RAM of ELF cartridges.

Space report →

Graphics editor

Sprites made of the TIA's objects, flicker phases, playfields row by row, animations, and kernels that decide what you can draw.

Graphics editor →

Music editor

Tracker and piano roll for the TIA's two channels, tuning in cents, sound effects, and sampled voices on ELF, DPC+ and CDFJ.

Music editor →

batari Basic

batari Basic 1.9 with its errors on the line of the .bas, and graphics kept up to date inside the program.

batari Basic →

C for ELF and ACE

C running on the cartridge's ARM, for the PlusCart, UnoCart and Chameleon Cart, with the ELF rules checked after linking, and ACE for the M4.

C for ELF and ACE →

AI assistant

Optional, and local first: a chat that knows the 2600 and your project, explains errors and proposes changes you review.

The AI assistant →

Knowledge base

All 256 6502 opcodes, the TIA and RIOT registers with their quirks, cartridge formats and TV standards. Press F1.

The knowledge base →

Themes

Dark, Light and two Solarized themes, or your own: every colour is a named role, and themes are files you can share.

Themes and languages →

Getting started

Install the tools, make a project from a template or an example, and learn your way around the panels.

Getting started →

Screenshots

A look inside

The graphics editor with a multicolour sprite
The graphics editor: a sprite made of layers, with its colour per row.
The space report after a build
The space report after a build.
The documentation panel showing NUSIZ0
F1 on a register opens its page in the knowledge base.
VCSIDE with the Solarized Light theme
The Solarized Light theme, with a shade per indentation level.

Licences

Free, and your games are yours

Download Getting started
